P524 Ride on Front Mower – Husqvarna

Description

Professional AWD Rider for Sale

As an all wheel drive model, the P524 ride on front mower is able to handle sloped surfaces like hillsides with ease. The AWD system automatically adjusts each of the wheels’ tractions to best suit the condition of the ground and the angle of your movement. As a result of this design, the P524 can handle any environment you throw at it.

The deck design also provides plenty of accessibility with a low profile and front mounting, so that you can mow wherever needed, even under areas that regular ride ons can’t easily access. This low, frontal positioning of the deck also means that you get maximum visibility over the workspace around you, so you will never miss a spot.

For convenience, you can use the quick coupling feature to efficiently switch between attachments, without needing any additional tools. The P 524 also has a cargo holder that you can use to chuck in extra equipment for the day’s work.

Not only that, the P524 ride on front mower also comes with a ladder frame made of heavy duty steel, and a rear wagon made of a single piece of cast iron. Both of these pieces of equipment provide additional options to the P524 and are highly durable.

Comfort Features of the P524 Mower

The P524 ride on front mower is designed to provide ideal comfort and ergonomics while you work. For example, the user interface provides an ergonomic ride experience, allowing you to work comfortably for longer. This is enhanced by the mower’s heavy duty power steering, which uses hydraulics to reduce the strain of driving over time.

The actual controls of the P524, as well as the servicing ports, are all easily accessible, making operation comfortable and maintenance simple. The wheels themselves, which are 16 inch on the front and back, also provide a lot of comfort and solid movement as you go.

To help extend this ride on front mower’s lifetime, it has greasable mandrels which are also easy to maintain. Additionally, when it’s time to clean out or service the cutting deck, it has a service position which simplifies both processes.

Husqvarna P524 Ride On Front Mower Specs

Item Number: 867 84 79-01, 8678479-01

Engine

• Power/Fuel Type: Gasoline
• Net power at preset rpm Energy: 13.9 kW
• Motor/engine manufacturer: Kawasaki
• Engine name: FX Series V-Twin
• Cylinder displacement: 726 cm³
• Cylinders: 2
• Engine cooling: Air
• Engine lubrication type: Full pressure
• Oil filter: Yes

Emission

• Exhaust emissions CO₂ EU V): 792 g/kWh

Battery

• Battery capacity: 24 Ah
• Battery type: Lead-Acid
• Battery pack weight: 5.4 kg
• Battery manufacturer: Global

Cutting deck

• Uncut circle: 50 cm
• Cutting width, min: 112 cm
• Cutting width, max: 122 cm
• Cutting height min: 25 mm
• Cutting height max: 80 mm
• Blade engagement: Electric clutch

Dimensions

• Tyre dimensions, front: 18×8.5-8
• Tyre dimensions, rear: 18×8.5-8
• Wheelbase: 100 cm
• Ground clearance: 105 cm
• Base machine, length: 205 cm
• Base machine, width: 98 cm
• Base machine, height: 117.4 cm
• Gross weight towed: 200 kg
• Weight (excl. cutting equipment): 427 kg

Drive system

• PTO (Power Take Off): Belt-driven
• Transmission type: Hydrostatic
• Transmission manufacturer, rear: Kanzaki
• Drive method: Dual pedal-operation
• Speed forward max: 13 km/h
• Speed reverse max: 5.6 mph
• Speed reverse max: 9 km/h
• Transmission manufacturer, front: Kanzaki
• Transmission model, front: KTM 23LB
• Transmission model, rear: KTM 23SB

Equipment

• Seat suspension: Yes
• Seat type: Premium
• Hour meter type: Digital
• Seat material: Vinyl
• Seat back height: High
• Foldable seat: Yes
• Steering wheel type: Professional
• Parking brake, type: Disc

Vibration

• Vibration level steering wheel: 3 m/s²
• Vibration level seat: 0.7 m/s²

Sound and Noise

• Sound pressure level at operator’s ear: 88 dB(A)
• Sound power level, guaranteed (LWA): 104 dB(A)
• Sound power level, measured: 102 dB(A)

Accessories Sold Separately

• 112 cm Combi Deck ($3399)
• 122 cm Combi Deck ($3599)
